型號　 參數

項目

冷卻方式

適用帶寬mm

額定吊高
h/ mm

磁場強度mT

蒸發冷卻勵磁功率KW

自然冷卻勵磁功率KW

驅動功率Kw

外型尺寸

L×W×Hmm　

適應帶速《m/s

整機重量Kg

RCDD-6.5

T1

自
然
冷 卻

650

200

90

5

4

1.5

2450×1440×650

4.5

1800

T2

120

7

6

2.2

2550×1140×675

1890

T3

150

11

10

2.2

2775×1140×690

1900

RCDD-8

T1

800

250

90

6.5

5.3

2.2

2700×1200×740

1920

T2

120

8.5

7.5

2.2

2700×1200×765

2560

T3

150

13

11.5

3

2700×1200×790

2900

RCDD-10

T1

1000

300

90

9

7.1

3

3010×1430×800

3100

T2

120

11

9.0

3

3010×1430×850

3700

T3

150

18

14

4

3010×1430×910

4600

RCDD-12

T1

1200

350

90

12

9

4

3460×1760×930

4320

T2

120

18.5

13.5

4

3460×1760×960

5320

T3

150

19.8

16

5.5

3460×1760×980

6100

RCDD-14

T1

1400

400

90

21

11.5

4

3800×1890×1040

6390

T2

120

25

15.0

5.5

3800×1890×1120

7400

T3

150

28

19.5

5.5

3800×1890×1180

8200

RCDD-16

T1

1600

450

90

26

18

5.5

4100×2300×1200

7150

T2

120

29

22

5.5

4100×2300×1230

8700

T3

150

39

26.5

7.5

4100×2300×1260

11750

RCDD-18

T1

1800

500

90

28

17.5

7.5

4600×2760×1250

9550

T2

120

33

25

7.5

4600×2760×1280

11540

T3

150

41

32.5

11

4600×2760×1300

15000

RCDD-20

T1

2000

550

90

35

22

7.5

5030×1850×1510

12460

T2

120

43

29.5

11

5030×1850×1580

14700

T3

150

50

36

11

5030×1850×1600
